Bentonite in Drilling Mud

Bentonite in Drilling Mud
Bentonite swells greatly when it meets water. It owns excellent colloid nature and can increase the viscosity of suspend fluid. While it is applied in drilling mud, it can improve the lubricating property of drilling tools and can clean the rock clinker.
Send Inquiry

Product Introduction

Bentonite swells greatly when it meets water. It owns excellent colloid nature and can increase the viscosity of suspend fluid. While it is applied in drilling mud, it can improve the lubricating property of drilling tools and can clean the rock clinker. It is widely applied in drilling constructions at stratums with complicated structures to avoid accident.

Bentonite minerals in nature are classified into the following specifications based on the percentage of exchangeable cations in the total particle exchange: sodium based bentonite, sodium calcium based bentonite, calcium sodium based bentonite, calcium based bentonite, magnesium calcium bentonite, calcium magnesium bentonite, and lithium based bentonite.

According to the different post-processing techniques of bentonite, it can also be divided into types such as organic bentonite, inorganic bentonite, and activated clay.



Specification



Item

Specification

600r/min

30mpas min

Yield point/Plastic Viscosity

3 max

Filtrate Volume ml

15 max

Moisture %

10% max

Residue of Diameter Greater than 75um%

4 max



Chemical Index



Item

Specification

SiO2

69.32

Al2O3

14.27

Fe2O3

1.84

FeO

0.63

CaO

1.99

MgO

2.69

Na2O

1.85

P2O3

0.04

TiO2

0.13

K2O

1.38



application


1. Mud formulation for drilling, foundation piles, and subway connecting walls
2. Adhesives for metallurgical casting
3. Chemical decolorizing agents and environmentally friendly treatment agents
4. Fungicides and adsorbents for feed and pharmaceutical use
5. Adhesives for refractory and ceramic materials
6. Other building material additives



Package



One metric ton woven polypropylene jumbo bag with polyethlene liner/25kg PP woven bags
